Special aluminum strip buckle for ceiling of oil station canopy-Windproof strip buckle

Aluminum strip gusset ceiling is made of aluminum alloy, Windproof aluminum strip gusset plateThe ceiling thickness is generally0.8/0.9/1.0/1.2 ， Windproof aluminum strip gusset plateThe ceiling surface structure is mostly rectangular, and the board width is 300mm , height 30mm, it is a sealed ceiling design. The aluminum strip buckle system is distributed in a long strip shape with distinct ridges. The ceiling plane shows the effect of high and low staggered, stereoscopic and dynamic due to the installation drop between the gusset plate and the inlay. The ceiling system is regular, generous, compact in arrangement, simple and elegant in shape, strong in stereoscopic and modern sense. For ceilings with sound absorption requirements, perforated plates or ceiling structures can be selected according to design regulations. You can also add a layer of sound-absorbing cotton paper or black flame-retardant cotton cloth to the back of the perforated board to achieve sound absorption effect.

       Aluminum strip buckle Manufacturer , Excellent quality,Thickness foot , No color difference ,good flatness, Fire Prevention , Windproof,Flame retardant. Also called high-side windproof aluminum strip buckle , After aluminum alloy material ,Machine drawing molding, The rare specifications are 200 面, 300 面 , Thickness 0.8-1.0mmLength 6 米 , Can also be customized length, Aluminum buckle with beveled edge , And then the middle fold back. Therefore, the intermediate sealing difficult form was processed. ,And close spell effect is good , Seamless.

        Windproof strip buckle All beautiful and flat: the board of windproof strip buckle is made of special aluminum material. , Plate edge height 30mm,The whole board looks thick and flat. , The windproof buckle collar has two specifications: shallow near right angle and shallow near oblique angle. Windproof strip buckleTight structure ,Strong water resistance: the device is constructed as a windproof special keel snap-on structure ,Strong tightness , No clearance , Strong water resistance; windproof strip buckle device fragmentary is the use of shallow keel, Strong windbreak, shallow and near keel with fixed modulus of card teeth , For windproof, a windproof card code is designed beside each card tooth. , Suitable for outdoor decoration , High safety.

Practical in the corridor, swimming pool, gas station, station, airport and outdoor decoration, such as waterproof, high windproof occasions. Windproof buckle series, with a common windproof buckle structure, has a strong windproof ability, such as the eaves of the open air or the wind pressure is larger.

       Gas stations or toll stations are generally used.Windproof aluminum bar buckle, I .e. S300 The wide windproof aluminum strip buckle is made of aluminum alloy. The main reason for adopting the windproof aluminum strip buckle of gas station is that there is a special windproof buckle structure for anti-corrosion and fire prevention. and ordinary CThe type of buckle is more windproof. The buckle also has a strong windproof ability due to the special installation method, and can be widely used in gas stations, gymnasiums, aisles, eaves and other open air or places with high wind pressure.

        Aluminum strip buckle ceilingIt will also be used in subways, airports, stations, these places are used C Shaped aluminum bar buckle, CShaped aluminum buckle is a closed aluminum buckle, with clean and atmospheric surface, beautiful appearance and various colors, clear and smooth lines, beautiful appearance suitable for the place of the organization, simple structure: the installation structure is a standard keel buckle structure, the appearance is flat, and there is no gap.

Kaimai brand,Focus on indoor and outdoor metal ceiling aluminum curtain wall , Products include metal aluminum gusset ceiling,Aluminum square ceiling ,Aluminum grille ceiling ,Aluminum strip buckle ceiling , aluminum composite plate,Aluminum veneer curtain wall customization; committed to providing customers with engineering one-stop overall solution of building materials products and services company. Welcome to inquire --- Huang Liping 13074271912

Responsible editor: KaimaiAluminum strip buckle suspended ceilingManufacturer - Huang Liping13074271912
