In view of the space deformation curtain wall of the roof design, the model optimization analysis of the exterior of the building can meet the feasibility of the curtain wall installation, and at the same time, try to be close to the original architectural modeling, and then design and analyze the curtain wall system. The exterior wall model of the building is optimized. First, the exterior wall is modified and analyzed. Considering the feasibility of economic application, processing and installation, it should be processed in the form of folded music. Due to the formation of the facade, the center of the plane is not on the same lead vertical line, and the radius also changes with the height of the layer. Therefore, in order to adapt to the facade shape, the curtain wall unit plate (plate) will appear four points. Not a coplanar situation. The continuous innovation of architectural appearance and the popularization of space shaped buildings have put forward more and more challenges to the design of curtain wall. In order to realize the appearance of the building, it is a subject that needs to be discussed continuously to meet the requirements of the performance of the curtain wall and the processing and installation.

The facade of the project is multi-curved, and the shuttle shape is used as the decorative material of the facade. As a steel structure building, the meaning of Tianyuan place makes the exterior wall of the building itself change in many ways. In the double-layer curtain wall system, the protection of the inner curtain wall, the application of new materials, and the control of the curvature of the ceramic rod curtain wall have become the focus of the project. How to better control the curvature of the outer curtain wall has become a difficult problem in the project. Let\'s follow Kaimai Xiaobian to understand what are the on-site control measures for the surface quality of the decorative single-double-curved aluminum veneer curtain wall of the super high-rise building!

       1、单双曲面aluminum veneer curtain wallSurface Degree Building Attitude Feature

The exterior of the building is formed by the intersection of two irregular spatial arcs. The arc rotates into an arc body. Arc rotation B arc body two arcs intersect. Hyperbolic aluminum veneer curtain wall building curtain wall skin formation.

The building is a free space distortion without any rules. The center of each elevation position plane is not on the same lead vertical line, and the radius of the circle is also different. The shape is extremely complex and there are no rules to follow.

       2、单双曲面aluminum veneer curtain wallOptimization Analysis of Surface Degree Shape

For the design of the curved curtain wall in the space, the model optimization analysis of the exterior of the building can meet the feasibility of the curtain wall installation, and at the same time as close as possible to the original architectural modeling, and then the curtain wall system is designed and analyzed.

In order to optimize the exterior model of the building curtain wall, the exterior wall is first analyzed in layers. Considering the economic application, the feasibility of processing and installation, we should adopt the method of folding music. Due to the formation of the facade, the center of the plane is not on the same lead vertical line, and the radius also changes with the height of the layer. Therefore, in order to adapt to the elevation shape, there will be four non-coplanar conditions.

The total number of licences for this engineering unit is 7,658. The board warpage value varies from 0mm to 25mm with no regular variation. In order to solve the problem of plate warping, it can not only meet the feasibility of installing curtain wall, but also try to be close to the original architectural modeling. Each layer of the aluminum veneer curtain wall is optimized for the shape of the fold line, and the adjacent upper and lower layers are separated.

Due to the special shape of the facade, the adjacent floor is a wrong layer without any regularity

       3、单双曲面aluminum veneer curtain wallSurface Degree Design Analysis

Aiming at the design of the interlayer curtain wall, without any regularity on the adjacent floor, we designed a separate sink method, that is, the top beam of the unit board is divided into the top horizontal material and the sinking material, and the top horizontal material is connected with bolts. Adapt to the side line of the curtain wall of this layer, the sink material adapts to the edge line of the upper curtain wall, and the positional relationship between the aluminum veneer top beam of the exterior wall and the material of the water tank can be continuously adjusted, thus solving the design problem of irregular curtain wall.

       4、单双曲面aluminum veneer curtain wallFactors affecting the quality of curtain wall surface

① Position deviation of embedded parts and adapter and positioning deviation of vertical keel

② Turning point position of transverse keel

③ Fixed point position of pottery stick

       Architectural design has set off a climax of innovation all over the world. The appearance of buildings is constantly trying to break the limit, and the appearance of space-like buildings is becoming more and more common and popular. Curtain wall, as the external maintenance structure of the building, directly affects the visual effect of the building. In order to realize the appearance of the space special-shaped building and meet the safety of the curtain wall system structure, each performance is reliable, and higher and higher requirements are put forward for the design of the curtain wall company. The application of unit curtain wall in high-rise buildings is more and more extensive. For the architectural appearance of the modeling square, the curtain wall design is easy to realize. Aluminum veneer curtain wall manufacturers believe that for the appearance of regular curved surface modeling buildings, curtain walls adopt folding and special-shaped plate processing methods. Realization. However, it is difficult for traditional design ideas to be used only for the appearance of buildings with spatial heterogeneity and irregular changes.
