Aluminum grille ceiling-Installation method and method of installation steps

       随着生活水平的提高，现在的人越来越注重室内装修，各种各样的装修材料出现在我们的面前，让我们眼花缭乱，Aluminum grille ceiling也是室内装修的一种，下面小编就来给大家介绍一下Aluminum grille ceilingThe basic knowledge, let everyone better understand the aluminum grille ceiling.

       Aluminum grille ceiling-Aluminum grille ceiling operation process

       确定好高度，在墙上用墨斗弹高水平线2.用铁的膨胀栓把吊筋固定在顶上，吊筋下面固定轻钢龙骨要保持水平（如果格栅跨度不超过3米就不需要吊筋了），用水泥钉把铝角线沿水平线钉好把Aluminum grille ceilingPut the set on the ground and put it together completely. Place the set of grid ceiling on the aluminum angle iron, and tie the middle position directly on the light steel keel with thin iron wire.

       Aluminum grille ceiling-Aluminum grid ceiling bullet line method

       用水准仪在房间内每个墙（柱）角上抄出水平点（若墙体较长，中间也应适当抄几个点），弹出水准线（水准线距地面一般为500㎜），从水准线量至吊顶设计高度，用粉线沿墙（柱）弹出水准线，即为Aluminum grille ceilingThe lower leather line. At the same time, according to the ceiling plan, the main keel is ejected from the concrete roof. The main keel should be divided from the center of the ceiling to both sides with a maximum spacing of 1000 ㎜, and the fixing points of the boom should be marked. The spacing between the fixing points of the boom should be 900 ㎜ ~ 1000 ㎜. If the fixing points of beams and pipelines are larger than the requirements of design and regulations, the fixing points of suspenders shall be added.

       Aluminum grille ceiling-Aluminum grille hanging fixed hanging rod

       采用膨胀螺栓固定吊挂杆件。可以采用ф6的吊杆。吊杆可以采用冷拔钢筋和盘圆钢筋，但采用盘圆钢筋应采用机械将其拉直。吊杆的一端同L30*30*3角码焊接，（角码的孔径应根据吊杆和膨胀螺栓的直径确定）另一端可以用攻丝套出大于100㎜的丝杆,也可以买成品丝杆焊接。制作好的吊杆应做防锈处理，吊杆用膨胀螺栓固定在楼板上，用冲击电锤打孔，孔径应稍大于膨胀螺栓的直径。

Aluminum grid ceiling-light steel keel installation

The light steel keel shall be hung on the hanger rod (if the suspended ceiling is low, this process can be omitted and the next process can be carried out directly). Generally use 38 light steel keel, spacing 900 ㎜ ~ 1000 ㎜. The light steel keel shall be installed parallel to the long direction of the room, and shall be arched at the same time. The arching height shall be 1/200~1/300 of the room span. The cantilever section of light steel keel should not be greater than 300 ㎜, otherwise the boom should be added. The extension of the main keel shall be butted, and the butt joints of adjacent keels shall be staggered. Light steel keel after hanging should be basic.
