How much is the labor cost of aluminum grille ceiling?

       Aluminum grille ceiling How much does the installation cost cost? This problem is confused by many customers who purchase aluminum grille ceiling. The labor cost for installation in the market is uneven. In fact, the most important thing is that they do not understand or understand the steps of aluminum grille installation, resulting in their confusion and inability to estimate the cost of aluminum grille ceiling labor cost! In fact, a small aluminum grille ceiling can be completed by one person alone,Aluminum grille ceilingWhat are the installation steps? Let\'s learn together.

Aluminum grille installation first step: install the hanger bar

According to the floor elevation horizontal line, according to the design elevation, along the wall, pop up the ceiling elevation horizontal control line and keel sub-control line. And pay attention to whether there is any contradiction with the elevation of hydropower, and if there is any contradiction, solve it in time.

After playing the horizontal line of the ceiling elevation, determine the elevation of the lower end of the hanger rod, weld the upper part of the hanger rod with embedded steel bars or fix it into the top plate of the structure with angle steel while punching holes and expansion bolts, while connecting with the hanger rod.Ф 10 Galvanized steel wire shall be welded firmly. After the wire is hoisted, the wire shall be inserted into the adjusting spring plate, which shall be galvanized. The vertical and horizontal spacing of the boom is about 1200mm.

Aluminum grille installation step 2: pre-installed grille

Layout, calibration and painting of pipelines in the ceiling: after installation and calibration of water and electricity pipelines in the ceiling, paint on the structural ceiling and pipelines.1-2 times black paint. Separate the grid ceiling (110*110) strips of specifications underground first, and pre-assemble them into groups according to their specifications. Pay attention to the smooth and clean ground, and check the splicing flatness and firmness of the joist.

Aluminum grille installation step 3: hoisting grille

将预装好的每组Aluminum grille ceiling , installed in diameterФ the hook of 4mm galvanized iron wire, put one end of the hook into the main bone hole, and fix one end on the spring plate. Each set of joists connects each raster bar by a dedicated connector.

Aluminum grille installation fourth step: leveling

After connecting the whole grid ceiling, straighten the wire at the bottom of the joist according to the control line on the wall, and adjust it to the required level by adjusting the spring sheet.

Aluminum grille installation step 5: install the side keel

According to the ceiling elevation line, embed anti-corrosion wooden wedges around the wall and fixed them with cement nails.25*25 side keel, fixed spacing is not more than 400mm, side keel yin-yang angle junction splicing angle into 45, requires the side keel to be fixed firmly, flat.

Aluminum grille ceiling In fact, the installation is not very difficult, but the steps are complicated and the details are very important. As long as the key of each step is put in place, it will be easy to install.Aluminum grille ceilingYes! If you are interested in the above aluminum grille ceiling or have questions, please click to contact our online customer service, or call:13074271912, Kaimai Building Materials-Do a good job of ceiling with your heart!
