Kaimai Building Materials Squarealuminum grille ceiling how to install?

　   The aluminum grille ceiling system has good ventilation effect, high fire resistance, simple installation, exquisite structure, rich layers, open three-dimensional effect, beautiful appearance after decoration, rich colors and durable, and can be customized in any color. Square aluminum grille You can install additional grille lights, downlights, etc. The grille ceiling has different space options and can be installed in combination with the modeling board to make the scene more distinctive. The standard width of the conventional grille (single beam sees a smooth surface from the bottom) is 10mm, 15mm, 20mm, etc., can also be customized according to the requirements of special specifications, side view height of 30mm, 40mm, 50mm, 60mm and 80mm to choose from, can also be customized according to the requirements of special specifications. Only to understandSquare aluminum grille Understand how to install Square aluminum grille , let\'s learn together.

       One: understandingSquare aluminum grille smallpox specifications parameters:

1.Material: iron, aluminum alloy;2.常用格子：200mm*200mm、300mm*300mm、400mm*400mm、500mm*500mm；

3.Common bottom width:20mm, 25mm, 30mm, 40mm;

4.Common side height:40mm, 45mm, 50mm, 60mm, 80mm, 100mm, 120mm;

5. Plate thickness: 0.8 mm-3.0mm;

6. Coating process: roller coating, powder spraying, transfer wood/stone grain, fluorocarbon paint;

7. Expression form: square lattice, triangular lattice, hexagonal lattice, and special artistic modeling can also be customized.

     Two: understandSquare aluminum grilleInstallation process:

1. Determine the height and use ink to play the high horizontal line on the wall;

2. Fix the boom on the top with an expansion bolt, and fix the light steel keel below the boom to keep it level;

3. Use cement nails to nail the aluminum corner line along the horizontal line;

4. Put the aluminum grid on the ground, and complete the main and auxiliary bone assembly;

5. Place the assembled aluminum grille on the aluminum corner line, and hang the middle position directly on the light steel keel with the grille hanging code;

6. Adjust the level, clean.
