办公写字楼的吊顶材料aluminum gusset platehow to install?

       随着整体国民生活的提升，大型商务办公写楼的吊顶装修也越来越讲究。要环保，要轻质，要防火，要耐用，要吸音，还要性价比高等等；要符合这种大型商务办公写字楼的吊顶材料aluminum gusset platehow to install?

       1.首先的话我们要为需要安装aluminum gusset plateAccording to the horizontal line of different floor elevations, use the ruler vertical vector to the ceiling design elevation, and then bounce the horizontal line of the top elevation on the wall.

2. When the bullet line is completed, we will install the main keel boom. When the elevation under the boom can be determined, we can fix the bolt-free end of the boom under the floor with expansion bolts according to the keel position and the hanging spacing.

3. When the first two items are installed, we can fit the nut of the hanger rod, first install the hanger on the main keel, then insert the hanger into the corresponding hanger rod bolt according to the position of the sub-gear line, then connect the main keel, then install the connecting piece, attach the main keel to the hole, and set and connect the clamping.

4. Next, we will install the secondary keel and aluminum edge strips. According to the sub-keel dividing line that has been played, we will put the triangular hanging parts of the secondary keel. Wooden keel is used. Generally, the spacing of the secondary keel is 600mm. According to the spacing of the main keel specified in the design, the secondary keel is hung on the main keel through triangular pendants. The elevation of the ceiling is required to be fixed with cement nails around the wall.

       5.最后就是安装我们的主要材料aluminum gusset plateWell, during installation, we should gently press along the flanging place, completely clamp the two sides of the square plate into the keel, then push it tightly without violence, and then straighten the side aluminum strip card to fix the side aluminum plate.

       aluminum gusset plateInstallation Precautions

       1.根据Aluminum gusset ceilingThe design elevation of the spring line on the surrounding wall, the spring line should be clear, accurate position, its horizontal allowable deviation of 5mm.

2. Fix angle aluminum along the elevation line. The role of angle aluminum is to seal the edge of the ceiling. The common specification of angle aluminum is 25*25mm, and its color should be the same as that of aluminum alloy panel. Angle aluminum is fixed on the wall column with cement nails.

3. Determine the position line of the keel, because each aluminum alloy block plate is a formed veneer, and generally no longer can be cut into blocks. In order to ensure the integrity and installation reliability of the ceiling veneer, it is necessary to arrange the structural size of the ceiling frame according to the size of the aluminum alloy and the area size of the aluminum gusset ceiling. The basic arrangement of aluminum alloy square plate facing is: the plate combination should be complete, when leaving edges around, the surrounding edges should be symmetrical and uniform, and the arranged dragon skeleton position line should be drawn on the top of the elevation line.

       4.在安装Aluminum gusset ceilingWhen, should pay attention to the main keel hanging point spacing, according to the design recommended series selection, the middle part should be arched, keel arching height is not less than 1/200 of the room surface span. The position and height of the main keel shall be corrected in time after installation. To control the leveling of the dragon skeleton, first pull out the vertical and horizontal elevation control lines, and adjust the suspension height of the boom while installing it from one end. After the large surface is leveled, adjust some single keels with curved edges until the leveling meets the requirements.

       aluminum gusset plateIt is a good decoration material. When choosing this material, everyone needs to know how to install it correctly.
